WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) Quick Review on Essential Variables 1-Guide (Position) AWS D1.1, Table 4.1, WPS Qualification CJP Groove Weld (Plate or Tubular), or Fillet Weld (Plate or Tubular) Qualification Test: Position Tested 1G, 1G (Rotated) 2G 3G 4G 5G (2G+5G), 6G, 6GR 1F, 1F (Rotated) 2F, 2F (Rotated) 3F 4F (Plate) 4F (Tubular) 5F
Position Qualified* Qualified* F F, H V OH F, V, OH All F F, H V OH F, H, OH All
* CJP Groove Qualify CJP, PJP and Fillet Welds * Fillet Qualify Fillet only * Groove weld on plate qualifies pipes equal to or greater than 24 in [600 mm] nominal outer diameter. * Vertical uphill to downhill or vice versa is essential variable * Plug/Slot Welding Qualifies for Only the Positions Tested ( except See AWS D1.1, Table 4.5: PQR Essential Variables (except ESW and EGW process), for Non-CVN Testing Applications See AWS D1.1, Table 4.6: PQR Supplementary Essential Variables (except ( except ESW and EGW process), for CVN Testing Applications See AWS D1.1, Table 4.7: PQR Essential Variables for ESW and EGW process PAGE 1 OF 6
WPSAmerica.com
WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) 2-Guide (Thickness/Diameter of Base Metal Range) Test on Plate, CJP Groove Welds: T: Thickness of Test Coupon Welded
T from 1/8 in. (3 mm), but less than 1 in. (25 mm): Qualified Thickness Range: 1/8 in. (3 mm) Min., 2T Max. T from 1 in. (25 mm) and over: Qualified Thickness Range: 1/8 in. (3 mm) Min., Unlimited T test on ESW and EGW: Qualified Thickness Range: 0.5T Min., 1.1T Max. Note “d” of AWS D1.1, Table 4.2: CJP groove weld qualification on any thickness or diameter shall qualify any size of fillet or PJP groove weld for any thickness or diameter (see Clause 4.1 1.3 for Macroetch tests requirement). Test on Plate (Pipe), PJP Groove Welds: S: Thickness of Test Groove Depth
S from 1/8 in. (3 mm), to 3/8 in. (10 mm): Qualified Thickness Range: 1/8 in. (3 mm) Min., 2S Max. S over 3/8 in. (10 mm) to 1 in. (25 mm), incl.: Qualified Thickness Range: 1/8 in. (3 mm) Min., Unlimited Note “d” of AWS D1.1, Table 4.3: Any PJP qualification shall also qualify any fillet weld size on any thickness. Fillet Weld WPS Qualification (Qualify all Plate/Pipe Thickness): Test shall be based on Max. single pass and Min. multiple pass fillet weld size to be used in construction (See AWS D1.1, Table 4.4).
PAGE 2 OF 6
WPSAmerica.com
WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) 3-Guide (Diameter of Base Metal Range) Test on Pipe (Tube), CJP Groove Welds: a) Job Size Test Pipes: Diameter over or less than 24 in. (600 mm OD)
T from 1/8 in. (3 mm) to 3/8 in. (10 mm), incl.: Qualified Thickness Range: 1/8 in. (3 mm) Min., 2T Max. T over 3/8 in. (10 mm), but less than 3/4 in. (20 mm): Qualified Thickness Range: 0.5T Min., 2T Max. T from 3/4 in. (20 mm) and over: Qualified Thickness Range: 3/8 in. (10 mm) Min., Unlimited Qualified Nominal Diameter of Pipe (Tube) Size: Test diameter and over b) Standard Test Pipes: 2 in. Sch. 80 (50 mm OD x 6 mm WT) or 3 in. Sch. 40 (75 mm OD x 6 mm WT) Qualified Thickness Range: 1/8 in. (3 mm) Min., 3/4 in. (20 mm) Max.
Qualified Nominal Diameter of Pipe (Tube) Size: 3/4 in. (20 mm OD) through 4 in. (100 mm OD) 6 in. Sch. 120 (150 mm OD x 14 WT) or 8 in. Sch. 80 (200 mm OD x 12 WT) Qualified Thickness Range: 3/16 in. (5 mm) Min., Unlimited Qualified Nominal Diameter of Pipe (Tube) Size: 4 in. (100 mm OD) and over Note “d” of AWS D1.1, Table 4.2: CJP groove weld qualification on any thickness or diameter shall qualify any size of fillet or PJP groove weld for any thickness or diameter (see Clause 4.1 1.3 for Macroetch tests requirement). PAGE 3 OF 6
WPSAmerica.com
WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) 4-Guide (Base Metal Selection) AWS D1.1 Table 4.8: Table 3.1, Table 4.9 and Unlisted Steels Qualified by PQR PQR Base Metal: WPS Base Metal Group Combinations Allowed by PQR Any Group I Steel to Any Group I Steel: Any Group I Steel to Any Group I Steel Any Group II Steel to Any Group II Steel: Any Group II Steel to Any Group II Steel Any Group II Steel to Any Group I Steel Any Group I Steel to Any Group I Steel Any Specific Group III Steel to Any Group I Steel: The Specific PQR Group III Steel Tested to Any Group I Any Specific Group III Steel to Any Group II Steel: The Specific PQR Group III Steel Tested to Any Group I or Group II Steel Any Specific Table 4.9 Steel to Any Group I Steel: The Specific PQR Table 4.9 Steel Tested to Any Group I Any Specific Table 4.9 Steel to Any Group II Steel: The Specific PQR Table 4.9 Steel Tested to Any Group I or Group II Steel Any Group III Steel to Any Group III Steel (or) Any Group IV Steel to Any Group IV Steel (or) Any Table 4.9 Steel to Any Table 4.9 Steel: Steels shall be of the same material specification, grade/type and minimum yield strength as the Steels listed in the PQR Any combination of Group III, IV, and Table 4.9 Steels: Only the Specific Combination of Steels listed in the PQR Any Unlisted Steel to Any Unlisted Steel or Any Steel Listed in Table 3.1 or Table 4.9: Only the Specific Combination of Steels listed in the PQR Note: Groups I through IV are found in Table 3.1 PAGE 4 OF 6 WPSAmerica.com
WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) 5-Guide (Preheat) The need for and the temperature of preheat are dependent upon a number of factors such as chemical analysis, degree of restraint of the parts being joined, elevated temperature, mechanical properties, and material thicknesses.
When welding two different material groups, the minimum preheat temperature required shall be the higher temperature for the material to be welded. For prequalified procedures, preheat applicable to the higher strength group, as per Note 1 of Table 3.1-AWS D1.1. Also, thickness referred to for the minimum preheat is the greater of the nominal thicknesses at the weld of the parts to be joined. AWS D1.1, Table 4.5: Decrease from preheat and interpass temperature above 25 F (15 C) [100 F (55 C) for GTAW] is essential variable. Note: AWS D1.1, Table 4.5 PQR Essential Variables (except ESW and EGW process), for Non-CVN Testing Applications 6-Guide (Joint) AWS D1.1, Table 4.5: Essential Variables for Joints: -A change in groove type (e.g., single-V to double-V), except qualification of any CJP groove weld qualifies for any groove detail conforming to the requirements of 3.12 (PJP-Figures 3.3) or 3.13 (CJP-Figures 3.4).
-A decrease in the groove angle and root opening, an increase in the root face exceeding the tolerances (increase in the groove angle above 10 degree) for any groove detail conforming to the requirements of 3.12 (PJP-Figures 3.3) or 3.13 (CJP-Figures 3.4), 3.13.5 and 5.22.4.1 or 5.22.4.2 (Tubular and Nontubular). -The omission, but not inclusion, of backing or backgouging -A change in the type of groove to a square groove and vice versa Note: AWS D1.1, Table 4.5 PQR Essential Variables (except ESW and EGW process), for Non-CVN Testing Applications PAGE 5 OF 6
WPSAmerica.com
WPSAmerica.com AWS D1.1 (Structural Welding Code-Steel) 7-Guide (Heat input) See AWS D1.1, Table 4.5: PQR Essential Variables (except ESW and EGW process), for Non-CVN Testing Applications See AWS D1.1, Table 4.6: PQR Supplementary Essential Variables (except ESW and EGW process), for CVN Testing Applications See AWS D1.1, Table 4.7: PQR Essential Variables for ESW and EGW process AWS D1.1, 5.7 Heat Input Control for Quenched and Tempered Steels: When quenched and tempered steels are welded, the heat input shall be restricted in conjunction with the maximum preheat and interpass temperatures required. Such considerations shall include the additional heat input produced in simultaneous welding on the two sides of a common member. The preceding limitations shall be in conformance with the producer’s recommendations.
The increase may be measured by the following: Heat input [J /in. (J/mm)] = (Voltage x Amperage x 60)/ Travel Speed [in./min (mm/min)] 8-Guide (Welding Process) Essential Variables for SMAW, SAW, GMAW, FCAW, GTAW Process: AWS D1.1, Table 4.5 PQR Essential Variables, for NonCVN Testing Applications AWS D1.1, Table 4.6 PQR Supplementary Essential Variables, for CVN Testing Applications Essential Variables for ESW, EGW Process: AWS D1.1, Table 4.7 PQR Essential Variable Changes Requiring WPS Re-qualification PAGE 6 OF 6
